[. . . ] X) MainboardG52-77881X10018Copyright NoticeThe material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice. TrademarksAll trademarks in this manual are properties of their respective owners. [. . . ] VoltNotchImportant* In Dual-Channel mode, make sure that you install memory modules of the same type and density in different channel DIMM slots. * To enable successful system boot-up, always insert the memory modules into the DIMM1 first. 17ATX 24-Pin Power Connector: JPWR1 This connector allows you to connect an ATX 24-pin power supply. To connect the ATX 24-pin power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. G 2ATX 4-Pin Power Connector: JPWR2 This 12V power connector is used to provide power to the CPU. +1 4Important Make sure that all the connectors are connected to proper ATX power supplies to ensure stable operation of the mainboard. serial ATA Connector: SATA1~4 This connector is a high-speed Serial ATA interface port. Important Please do not fold the Serial ATA cable into a 90-degree angle. 18MS-7788 Fan Power Connectors: CPUFAN1, SYSFAN1, SYSFAN2 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND. If the mainboard has a System Hardware Monitor chipset onboard, you must use a specially designed fan with speed sensor to take advantage of the CPU fan control. cPUFAN1/ SYSFAN2 SYSFAN1Parallel Port Connector: JLPT1 (optional) This connector is used to connect an optional parallel port bracket. The parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode. R 119Front USB Connector: JUSB1/ JUSB2 This connector, compliant with Intel® I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Front Panel Audio Connector: JAUD1 This connector allows you to connect the front panel audio and is compliant with Intel® Front Panel I/O Connectivity Design Guide. You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. Important The items under each BIOS category described in this chapter are under continuous update for better system performance. Therefore, the description may be slightly different from the latest BIOS and should be held for reference only. The Menu BarMain Menu Use this menu for basic system configurations, such as time, date etc. Advanced Use this menu to set up the items of special enhanced features. Overclocking Use this menu to specify the settings for DRAM timing and CPU features. 23M-Flash Use this menu to read/ flash the BIOS form storage drive (FAT/ FAT32 format only). [. . . ] 27Intel C-State C-state is a power management state that detects when the system is idle and lowers power consumption accordingly. Long duration power limit (W) This field allows you to adjust the TDP power limit for the long duration. Long duration maintained (s) This field allows you to adjust the maintaining time for long duration power limit. Short duration power limit (W) This field allows you to adjust the TDP power limit for the short duration. [. . . ]
